Capabilities & Details
ANBOT-Y Security Patrol Robot
Mainly applied to indoor and outdoor scenarios such as residential communities, office buildings, villas, and technology parks. Robots can collaborate with property security guards and management personnel to carry out 24-hour indoor and outdoor patrol duties, which can effectively improve the security capabilities and technological image of the park, and help the park become smarter and digitally upgraded, thereby reducing operating costs and improving management efficiency.
Product Details
Super navigation and obstacle avoidance capabilities : Based on ONEWAY team’s 10-year self-developed robot Low-speed automated driving (LSAD) systems, chassis motion control technology and modular chassis design with stable and reliable performance.
Support cross-floor and multi-area patrols : Through the self-developed gate&elevator IoT module, the robot can be linked with elevators and gate to achieve multi-area walking and cover a larger patrol area.
High-accuracy intelligent algorithm : Based on ONEWAY CLOUD's image deep learning and artificial intelligence technology capabilities, it has extremely high accuracy in identifying abnormal situations such as faces and intrusions.
Multi-scenario function adaptation : Different business functions and customized permissions can be configured for different types of application scenarios and user roles.
| Adapt to real estate scenarios | Self-developed full-stack technology | Automotive hardware platform | Support secondary development |
Product Features:
Autonomous driving
| Autonomous mapping | Fused positioning | Navigation planning | Fused sensing |
| Autonomous obstacle avoidance | One-click arrival | Self charging | Fault self-testing |
Basic functions
| Panoramic monitoring | Audio broadcast | Two-way intercom | Temperature & humidity monitoring |
Intelligent applications
| Patrol and take pictures | Face detection | License plate detection | Intelligent detection |
| Abnormal alarm | Patrol report | Record traceback |
Application scenarios:
Housing estate
Commercial office buildings
Product parameters:
Size
800x523x988mm
PTZ lifting height
300mm
Weight
70kg
| Protection level | IP55 (standard) |
Protection level
IP55 (standard)
| Operating temperature | -19°- 55° |
Operating temperature
-19°- 55°
| Adapt to walking surface | Indoor and outdoor flat roads |
Adapt to walking surface
Indoor and outdoor flat roads
| Control method | Autonomous walking｜Remote control｜RMS background｜Mobile APP |
Control method
Autonomous walking｜Remote control｜RMS background｜Mobile APP
| Temperature monitoring | Measuring range: -20°- 80° | Accuracy: ±0.2℃ |
Temperature monitoring
Measuring range: -20°- 80° | Accuracy: ±0.2℃
| Humidity monitoring | Range: 0-100%RH | Accuracy: 2%RH |
Humidity monitoring
Range: 0-100%RH | Accuracy: 2%RH
| Image Identification | Face detection｜License plate detection｜Pedestrian detection |
Image Identification
Face detection｜License plate detection｜Pedestrian detection
| Maximum climbing angle | 15° |
Maximum climbing angle
15°
| Maximum obstacle clearance height | 40mm |
Maximum obstacle clearance height
40mm
| Battery life | 4 hours (optional 8 hours) |
Battery life
4 hours (optional 8 hours)
| Shock absorption method | Four-wheel independent suspension |
Shock absorption method
Four-wheel independent suspension
| Sport mode | Two-wheel front drive |
Sport mode
Two-wheel front drive
| Fast charging | ≤2 hours (20%~90%) |
Fast charging
≤2 hours (20%~90%)
| Turning radius | Turn in place｜Turn radius is 0 |
