Capabilities & Details
APV-X special inspection robot
Mainly applied to special working scenarios such as military camps, border posts, airports, and military material warehouses. The six wheel robot chassis has strong passability, large load capacity and reliable performance. It can assist military officers and soldiers to complete tasks such as fixed-point duty, night patrol, material and equipment inspection, and remote visual reconnaissance in complex military combat environments, releasing troops and reducing potential risks. The robot is equipped with AI detection and interaction functions, which can cooperate with the military to complete military appearance and discipline inspections, political propaganda, and other work.
Product Details
Product advantages:
Super navigation and obstacle avoidance capabilities: Based on ONEWAY team’s 10-year self-developed robot Low-speed automated driving (LSAD) systems, chassis motion control technology and modular chassis design with stable and reliable performance.
All-terrain robot chassis: Equipped with a powerful six-wheel and six-wheel drive chassis and separate frame construction, it can easily pass 140cm obstacles vertically, adapting to all-terrain use.
High-accuracy intelligent algorithm: Based on ONEWAY CLOUD's image deep learning and artificial intelligence technology capabilities, it has extremely high accuracy in identifying abnormal situations such as faces and intrusions.
Panoramic monitoring without blind spots: The body is equipped with a high-resolution binocular PTZ camera and equipped with a thermal imaging camera. Panoramic monitoring has no blind spots and maximizes safety risk perception capabilities.
| Rock-solid military quality | Full stack self-developed technology | Automotive hardware platform | 1,000,000㎡mapping |
Product Features:
Autonomous driving
| Autonomous mapping | Fused positioning | Navigation planning | Fused sensing |
| Autonomous obstacle avoidance | One-click arrival | Automatic charging | Fault self-testing |
Basic functions
| Panoramic monitoring | Audio broadcast | Two-way intercom | Temperature and humidity monitoring |
| Intelligent Q&A | Infrared temperature measurement | One-key alarm | Smoke monitoring |
| Binocular PTZ camera | Gas monitoring |
Intelligent applications
| Patrol and take pictures | Face detection | License plate detection | Intelligent detection |
| Abnormal alarm | Patrol report | Record traceback | AI detection |
| Intelligent meter reading detection | Movement detection | Fire alarm |
Application scenarios:
Border post
Military camp area
Airport
Product parameters:
Size
1400x870x1250mm
Weight
250kg
| Protection level | IP55 (standard) |
Protection level
IP55 (standard)
| Operating temperature | -19°- 55° |
Operating temperature
-19°- 55°
| Adapt to walking surface | Indoor and outdoor roads｜All terrain |
Adapt to walking surface
Indoor and outdoor roads｜All terrain
| Control method | Autonomous walking｜Remote control｜RMS background｜Mobile APP |
Control method
Autonomous walking｜Remote control｜RMS background｜Mobile APP
| Maximum climbing angle | 20° |
Maximum climbing angle
20°
| Maximum obstacle clearance height | 140mm |
Maximum obstacle clearance height
140mm
Battery life
8 hours
| Shock absorption method | Six-wheel independent suspension |
Shock absorption method
Six-wheel independent suspension
| Sport mode | Six-wheel drive |
Sport mode
Six-wheel drive
Fast charging
4 hours
| Turning radius | Turn in place｜Turn radius is 0 |
Turning radius
Turn in place｜Turn radius is 0
| Motor | 600Wx6 1024 line photoelectric encoder |
Motor
600Wx6 1024 line photoelectric encoder
| Maximum autonomous navigation speed | 1.6m/s |
Maximum autonomous navigation speed
