Saturn

Capabilities & Details

PV Module Fitting Robot Saturn

Product Highlights

• High-speed precision, intelligent operation
• Reliable, trustworthy
• Flexible adaptation, broader compatibility

Technical Specifications

General and mechanical

• Dimensions 5600mm * 2200mm * 3400mm

5600mm * 2200mm * 3400mm

• Weight 8 t

8 t

• Ingress protection IP65 (Key components)

IP65 (Key components)

• Chassis type Tracked chassis

Tracked chassis

• Remote control distance 20 m

20 m

• Max arm-span of robotic arm 3.9 m

3.9 m

• Load of Robotic Arm 150 kg

150 kg

• Max load of forklift 1.5 t

1.5 t

• Warranty period 1 year or 2000 hrs (which ever comes first)

1 year or 2000 hrs (which ever comes first)

• Life cycle 10 years

10 years

• Running speed 2 km/h

2 km/h

• Mounting efficiency 60-100 panels per hour

60-100 panels per hour

• Placement tolerance ± 5 mm

± 5 mm

• Power type Diesel-Hybrid / EV

Diesel-Hybrid / EV

Adaptive capability

• Module type Supports mainstream types

Supports mainstream types

• Mounting stracture Tracker, Fixed tilt

Tracker, Fixed tilt

• Application scenario Utility-scale PV power plant

Utility-scale PV power plant

Environmental suitability

• Operating temp -20℃~ 55℃ (Customizable for temperatures below -20°C)

-20℃~ 55℃ (Customizable for temperatures below -20°C)

• Storage temp -25℃~ 65℃ (Customizable for temperatures below -25°C)

-25℃~ 65℃ (Customizable for temperatures below -25°C)

• Operating altitude ≤ 4000 m

≤ 4000 m

• Max wind speed (operating) ≤ 12 m/s (Strong breeze)

≤ 12 m/s (Strong breeze)

• Obstacle crossing height ≤ 350 mm

≤ 350 mm

• Max ditch width ≤ 900 mm

≤ 900 mm

• Max climbing angle 30°(Hard ground)

30°(Hard ground)

• Turning radius 2750 mm

2750 mm

Others

• Night operation Yes

Yes

• Active safety protection Yes
• Data management Yes
